Dekoron® Instrumentation Cable (PVC Insulation, Pairs, Triads, Overall Shield)

Dekoron Instrumentation Cable DC03

Dekoron® instrumentation cables were
pioneered starting in the 1940’s for the
process industry. These cables monitor
process parameters such as pressure,
flow speed, temperature and transmit
low voltage signals to the instrumentation
and process control room. Designed with
multiple twisted pair confi gurations with
each pair gathering one set of process
data. Used worldwide in petrochemical
and refi ning industries. (DC03)

Instrumentation Cable (PVC Insulation, Pairs, Triads, Overall Shield)

Assembly Code

Height

Depth

95 CSI

Masterformat Number

File Type

Subcategory

04 CSI

Width

Mounting

Brand

Manufacturer

OmniClass Number

Region

Product Line

District

Type

Visual Light Transmittance

Heat Transfer Coefficient (U)

Finish

Shape

Glazing Material

Operation

Green Certification

Solar Heat Gain Coefficient

Sustainable Solution

Rating

Analytic Construction

Models

Locker Panel Material

Unit Material

Max. Frame Rate

Max IP camera inputs

Total storage capacity

Camera Tilt

Camera Pan

Max. Resolution

Internal hard drives

Performance Flooring

Tile and Flooring Installation

Structural Panels

Exterior Envelope

UL Details

Ceilings

multivalue attribute

ProductLine

04CSI

95CSI

AssemblyCode

MasterformatNumber

Frame Type

Applications

Interior-Exterior

Weather Performance

Performance Ratings

Stacking Location

Stacking Direction

Frame

Glazing

Max Height Range

Max Unit Width Range

Max Panel Width Range

Panel Design Options

Sill

Tracks

Wall Design

Accessories

Swing Door

Hardware

Product Type

Configuration

Model

Estimated Power Output

Light Transmittance

Module Dimensions

Series

Mount

LSX Modules Deep

Vision S Modules Deep

Vision L Modules Deep

GSX Modules Deep

Assembly Type

Composition

Unit of Measure

Colors

Application

Material Look

Component Type

Framing Types

Fire

Assembly Thickness

Sound Transmission Class (STC)

Apparent Sound Transmission Class (ASTC)

Sound Absorption (NRC)

Sound Attenuation (CAC)

Light Reflectance

Door Type

Parting

Collection

Color Group

Size (width x length x thickness)

Thickness

Wearlayer/Coating Type

Installation Method

Fond du Lac Tailored Blend veneer stone accented with Indiana Silverbuff cut stone panel surrounds and architectural details make for the perfect stone siding combination on this modern home. This blend of authentic natural stone is the perfect genuine stone cladding to complete a contemporary look on all types of front entrance or indoor-outdoor stone designs. The sawn heights of Fond du Lac Tailored Blend satisfy the linear look of many modern architectural styles with the beauty of a rustic texture that brings us back to nature.

Fond du Lac Tailored Blend and Indiana Silverbuff Cut Stone

Fond du Lac Flagstone, Steppers, and Snapped Steps bring arctic stone colors to our Patio and Paving Stone and stone Steps Lines of landscape stone. By sourcing natural stone hardscape pieces for landscape design and full and thin stone veneers from the same quarries, we promote real stone material matching and symmetry among all parts of a stone project. Fond du Lac Flagstone’s artistic assemblage of irregular and random lengths and widths consists of real stone pieces ranging in diameters from 18″ to 48″ for stone products at both heights (1″ to 2″ and 1-3/4″ to 2-1/2″). Fond du Lac Stepper’s natural stone pieces range in diameters from 8″ to 24″ for products at both heights (1″ to 2″ and 1-3/4” to 2-1/2”). Fond du Lac Snapped Steps range in widths from 17″ to 19″ and 23″ to 25″ depending on coverage area selected (see spec sheet for coverage area options) and are available in 5″ to 8″ heights (lengths vary by coverage area). Grays, light grays, buffs, and whites make for a beautiful natural Fond du Lac stone color range

Fond du Lac Flagstone, Stepper & Steps

Surface and underground mining operations require cable solutions that can withstand the toughest conditions. Elements such as flexing, vibration, and impact found in harsh mining environments can make or break even the most rugged mining machinery. Marmon IEI understands how important high-performance and ruggedized cables are for critical power, control, and communications applications and offers a variety of specialized cables to meet any type of mining installation. From flexible power cables used in surface mining applications to MSHA-rated cables used in underground equipment, Marmon IEI has solutions that can perform in the toughest environment reducing downtime and keeping critical mining operations running.

Mining

Contact Sales Rep

Marmon IE&I Collection

Find Product Information, Download Submittals, Request Technical Services

Leaders in Innovative Design, Production, and Technical Support of Specialty Wire, Cable, Pre-Insulated and Steam Traced Tubing For Your Next Project

Marmon Industrial Energy & Infrastructure Technical Resources

Marmon IEI works within a wide variety of industries and markets.

Request A Quote

Technical Resources

Alchemco

Christie Digital

The Bilco Company

Stonepeak

Moore Co Inc

Rinnai America Corp

Cornell Cookson

Viessmann Digital

Tubelite

Jonti Craft

The Noble Co

Interstate Brick

MIRAGE Flooring

Armacell

Atkore International

GAF Materials

Novawall Systems, Inc.

System Level Account

Heating & Cooling Products

J&J / Invision

Armacell, LLC

Contrax (MeTEOR)

Georgia Pacific

Meteor Lighting

Draper, Inc.

Big Ass Fans/ Big Ass Solutions

Shaw Industries

Bernina Flooring

Keilhauer

Arconas

Davis Colors

Oldcastle Architectural

Media Technologies

Roxul

The VMC Group

Armstrong International - Hot Water Products

Carnes Co

Karona Door

Ideal Industries Inc

Tiger Foam - Commercial Thermal Solutions Inc

Kolbe & Kolbe Millwork Co., Inc.

InPro

VIA Inc [VIA Seating]

Nanawall

Armstrong Commercial Flooring

H.E. Williams, inc.

Acutherm

Penco Products, Inc.

Continental

Chief is a division of Milestone AV Technologies

Friedrich

Armstrong Medical Industries

Bard Manufacturing Co

Delray Lighting Inc.

Stepstone Inc

Knauf Insulation

USA Capitol

Moderco Inc

General Cable

Tandus-Centiva

Slant Fin

Armstrong International

ClimaCool

AmTab Manufacturing Corp

Power-Strut®

Owens Corning

NexLight

Caleffi

Coronet, Inc

Schott North America

Schneider Electric USA Inc

National Office Furniture, Inc.

Tarkett

Kimball Office

Prudential Lighting

Cardinal Detecto

Jeld-Wen, Inc.

American Gypsum

Property	Value
Construction - Color Code	1852-1859 = Black & White 1862-1869 = Black, White & Red
Construction - Conductor	7-Strand Bare Copper, Class B
Construction - Shield	100% Coverage, Aluminum/Polyester Tape Shield with 7-Strand Tinned Copper Drain Wire
Construction - Number of Conductors Per Group	1852-1859 = 2 1862-1869 = 3
Construction - Jacket	Black FR-PV
Construction - Insulation	1852 = 0.015 inch (0.4 mm) 105°C FR-PVC for < 16 AWG 0.015 inch (0.4 mm) 105°C FR-PVC for < 14 AWG • 1853-1869 = 0.015 inch (0.4 mm) 105°C FR-PVC
Performance Standards	Certifi ed Class 1, Division 2 Hazardous locations • NEC Article 725 & 727
Product Category	Instrumentation
UL Listings	Listed as “PLTC/ITC”
Volts	300
Construction - Cable Type	1852-1859 = Single Pairs Shielded • 1862,1863,1865,1869 = Single Triad Shielded • 1864 for Single Triad Unshielded

Product Details

Instrumentation Cable (PVC Insulation, Pairs, Triads, Overall Shield)
