Product Details
1S50 - 300 Volt, Silicone (Fire Resistant), Single Pair, Unshielded, Unarmored
Applications
Harsh Environment Power Control Instrumentation, Fire & Life Safety
Description
1S50 - 300 Volt Silicone (Fire Resistant) Cable is designed for high-temperature, fire-prone environments. It’s ideal for critical industrial applications, providing reliable performance where flexibility and fire resistance are essential.
Features
- Provides extended service while exposed to fire
- Made in America
- 300 Volt rated insulation
- Various metric and AWG size conductors
- Special color coding of insulation and jacket materials
| Property | Value |
|---|---|
| Applications | Harsh Environment Power Control Instrumentation, Fire & Life Safety |
| Construction - Bending Radius | 6 x d (d = overall diameter) |
| Construction - Color Code | Black and white |
| Construction - Cable Type | Single Pair Shielded |
| Construction - Insulation | 0.030 inch (0.8 mm) 90°C thermoset silicone alloy |
| Construction - Jacket | : Black TPN |
| Construction - Number of Conductors Per Group | 2 |
| Construction - Conductor | 7-strand bare copper, Class B |
| Market Served | Oil & Gas, Clean Energy |
| Performance Standards | ICEA, IEC, BS standards or customized configurations • BS 6387 C, S, W and Z • IEC 331 and BS 6387 C, S and Z fire tests • Class I, Division 2 and Class II, Division 2 hazardous areas • NEC 2023 Article 722/335 |
| Product Category | Circuit Integrity |
| Temperature | 750ºC |
| UL Listings | Manufactured in accordance with UL • PLTC/ITC |
| Volts | 300 |
