Product Details
| Property | Value |
|---|---|
| Construction - Fillers | (When required) |
| Construction - Conductor | Annealed copper, Class “B” strand per ASTM B3 & B8 |
| Construction - Circuit Identification | Printed numbers per ICEA Method 4 (14-10 AWG Method 1, Table E-2) |
| Construction - Binder Tape | Helically applied |
| Construction - Armor | Continuously welded and corrugated aluminum |
| Product Category | Power, Circuit Integrity |
| Performance Standards | Class I, Division 1 hazardous locations • ASTM D746-04 brittleness temperature impact test at -75°C • MIL-C-13777 cold bend test at -65°C • UL with the “–40°C” designation meeting the cold impact requirement of CSAC22.2 No. 0.3 • ICEA S-95-658 • ICEA210,000 BTU/hr and 70,000 BTU/hr flame tests and the IEEE-383 70,000 BTU/hr flame test • ABS Recognized |
| Volts | 600 |
| UL Listings | NEC Type MC-HL, UL 2225 • UL 44 for type XHHW-2 •70,000 BTU/hr flame test, as per UL 1685 and is UL listed for CT use • UL approved and marked with the IEEE 1202/FT-4 designation (flame test) • Type CWCMC to IEEE 1580 (46 CFR Part 111.60-23) Marine Shipboard Cable |
| Construction - Jacket | Arctic Grade Flame retardant polyvinyl chloride (PVC) |
| Construction - Insulation | Arctic Grade Crosslinked polyethylene (XLPE) |
| Construction - Ground Wire(s) | Annealed copper, Class “B” strand, sizes per NEC requirements |
| Applications | Harsh Environment Power Control Instrumentation |
| Market Served | Oil & Gas |
| Temperature | 90ºC |
