Product Details
| Property | Value |
|---|---|
| cUL Listing | CEC Type CIC • CEC Type TC |
| CSA Listings | CSA Standard C22.2 No. 239 • CSA Standard C22.2 No. 230 • CSA 22.2 No. 38 Section 5.4 |
| Volts | 600 |
| UL Listings | NEC Type TC with UL 1277 • UL44 • UL Type RFHH-3 |
| Performance Standards | 30 minutes at 2000°F (1093°C ) Rapid Rise test witnessed by UL, modified IEC 60331 with side bricks and light bulb load • IEC 60331-11 flame test modified to 3 hours @ 2000°F • Sunlight Resistant • FT-4 flame test designation • ABS Recognized for marine shipboard • -ER meets crush and impact requirement of Type MC cable and can be used per NEC 336.10 (7) for extended runs |
| Construction - Overall Shield System | Components and overall cable shields, if required, accomplished by copper polyester tape shield in contact with stranded copper drain wires. |
| Construction - Jacket | Black Low-Smoke Zero Halogen Polyolefin (colors available on request) |
| Construction - Insulation | Proprietary Low Smoke Zero Halogen thermoset Fire-Roc layer and thermoset low smoke zero halogen covering |
| Construction - Conductor | Stranded, nickel coated copper |
| Construction - Circuit Identification | ICEA Method 3 Table E1: Black insulation with printed pair numbers and color names — black and white for pairs — black, white and red for triads. In addition, legs other than black have colored stripe in the named color. |
| Construction - Binder Tape | Helically applied binder tape applied over unshielded and multi-pair or multi-triad cable cores. |
| Product Category | Circuit Integrity, Instrumentation |
| Region | Canada |
| Applications | Fire & Life Safety |
| Market Served | Oil & Gas, Clean Energy |
| Temperature | 90ºC, 75ºC |
