Property	Value
Product Category	Thermocouple
Bending Radius	6 x D (D = overall diameter)
Cable Type	Single Pair, Shielded
Construction - Color Code	ANSI Standard
Construction - Conductor	Solid Alloy Wire
Construction - Insulation	0.015 inch (0.4 mm) 105°C PVC
Construction - Communication Wire	22 AWG Solid Bare Copper, Orange FR-PVC Jacket • Jacket: FR-PVC, ANSI Color-Coded
Construction - Jacket	FR-PVC, ANSI Color-Coded
Construction - Overall Shield System	100%-Coverage Aluminum/Polyester Tape Shield with 7-Strand Tinned Copper Drain Wire
UL Listings	“PLTC/ITC” • Manufactured in Accordance with UL
Volts	300
Applications	Harsh Environment Power Control Instrumentation
Market Served	Oil & Gas, Clean Energy
Performance Standards	ICEA, IEC, & BS Standards or Customized Configurations • Class I, Division 2 hazardous locations • NEC 2023 Article 722/335

Product Details

1802 - 300 Volt, PVC, Thermocouple Extension, Single Pair, Overall Shield, Unarmored
