Product Details
| Property | Value |
|---|---|
| Construction - Insulation | Irradiation cross-linked polyolefin |
| Construction - Ground Conductor | Three segmented, green insulated grounding conductors with the same voltage rating as the circuit conductors |
| Construction - Fillers | Flame retardant fibrillated polypropylene, as required |
| Applications | Flexing |
| Market Served | Mining & Industrial OEM |
| Temperature | 90ºC |
| UL Listings | Type XHHW-2 per UL 44 and Type XLPE per ICEA S-75-381 • UL 1277 and ICEA S-75-381 |
| Product Category | Power |
| Performance Standards | Cable meets cold temperature requirements - -40˚C cold impact, -55˚C cold bend • IEEE 1202/FT4 Flame Test |
| Construction - Jacket | Black, heavy-duty, arctic grade neoprene |
| Construction - Conductor | Annealed, flexible tinned copper, Class I per ASTM B33 & B172 |
| Construction - Circuit Identification | Power conductors – Dark gray, red, blue; Ground conductors – Green |
