Product Details
| Property | Value |
|---|---|
| Construction - Circuit Identification | ICEA Methd 3: Black single conductors with printed numbers and color name, following K-2 sequence |
| Construction - Binder Tape | Helically applied |
| Volts | 600 |
| UL Listings | API 2218 flame test per UL 1709 oven test at 2000°F for 60 minutes with heat flux of 65,000 ± 5000 BTU/h – ft2 (204 ± 16 kw/m2) • NEC Type TC in accordance with UL 1277 • Singles UL Type RHW-2 suitable for wet locations • UL 44 |
| Product Category | Circuit Integrity, Power, Control |
| Performance Standards | Approved and marked with “FT-4” flame test designation • ABS Recognized for marine shipboard • -ER meets the crush and impact requirement of Type MC cable and can be used per NEC 336.10 (7) for extended runs |
| cUL Listing | CEC Type CIC • CEC Type TC i • CUL Listed RW90 |
| CSA Listings | R90 in accordance with CSA C22.2 No. 38 • CSA Standard C22.2 No. 239 • CSA Standard C22.2 No. 230 |
| Construction - Thermal Barrier | Inorganic layer |
| Construction - Jacket | Black Low-Smoke Zero Halogen Polyolefin (colors available on request) |
| Construction - Insulation | Proprietary Low Smoke Zero Halogen thermoset Fire-Roc layer and thermoset low smoke zero halogen covering |
| Construction - Ground Wire(s) | Insulated ground wire upon request |
| Construction - Conductor | Stranded, nickel coated copper |
| Region | Canada |
| Applications | Fire & Life Safety |
| Temperature | 90ºC |
| Market Served | Oil & Gas, Clean Energy |
