Product Details
| Property | Value |
|---|---|
| cUL Listing | CEC Type CIC • CEC Type TC |
| UL Listings | NEC Type TC in accordance with UL 1277 • UL44/CSA 22.2 No. 38 Section 5.4 Long Term Insulation Resistance in Water Test. • Singles UL Type RFFH-3 |
| Construction - Insulation Shield | Overall cable shield, accomplished by copper polyester tape shield in contact with stranded copper drain wires |
| Construction - Conductor | Stranded, nickel coated copper |
| Performance Standards | Insulation resistance is in excess of 10,000 ohms in 60 minute 2000°F flame test per Mil-W-25038 • 30 min. @ 2000°F witnessed by UL • IEC 331 flame test modified to 3 hours @ 2000°F • Sunlight Resistant • FT-4 flame test designation • ABS Recognized for marine shipboard • - Type MC cable and can be used per NEC 336.10 (7) for extended runs |
| Volts | 600 |
| Product Category | Communications, Fieldbus, Circuit Integrity |
| CSA Listings | CSA Standard C22.2 No. 239 • CSA Standard C22.2 No. 230 • CSA 22.2 No. 38 Section 5.4 |
| Construction - Circuit Identification | ICEAMethod 3: Black insulation with printed numbers and color names — black and white for pairs — black, white and red for triads. In addition, legs other than black have colored stripe in the named color |
| Construction - Jacket | Black Low-Smoke Zero Halogen Polyolefin (colors available on request) |
| Construction - Insulation | Proprietary Low Smoke Zero Halogen thermoset Fire-Roc layer and thermoset low smoke zero halogen covering |
| Region | Canada |
| Applications | Fire & Life Safety |
| Market Served | Oil & Gas, Clean Energy |
| Temperature | 90ºC, 75ºC |
