Product Details
| Property | Value |
|---|---|
| Construction - Conductor Shield | Permashield® conductor shield (non-conducting stress control layer) |
| Construction - Insulation | Proprietary Kerite® discharge resistant insulation |
| Construction - Insulation Shield | Thermoset semiconducting layer |
| Construction - Barrier Tape | Flame barrier tape(s |
| Construction - Jacket | Flexible, thermoset low smoke zero halogen (LSZH) |
| Construction - Metallic Shield | 5 mil helically applied tinned copper tape with 20% overlap |
| Construction - Conductor | Bare copper (tinned copper also available), class “B” compressed strand (compact strand also available) |
| Performance Standards | ICEA S-97-682 and S-93-639 or S-68-516 and AEIC CS-6 • Class 1E qualified with IEEE 383-1974/2003 and IEEE 323-1974/2003 – Nuclear qualified with a minimum 60 year thermal life expectancy at 90°C – Radiation resistant (up to 220 megarads) • IEEE 383-1974 vertical tray flame test and IEEE 1202 vertical tray flame test • 10 CFR Appendix B • Full traceability • ICEA standard S-93-639 |
| UL Listings | UL 1685 |
| CSA Listings | CSA FT4 |
| Product Category | Power |
| Applications | Harsh Environment Power Control Instrumentation |
| Market Served | Nuclear |
| Temperature | 90ºC |
| Volts | 600 |
