Product Details
| Property | Value |
|---|---|
| Construction - Barrier Tape | Helically applied |
| Construction - Armor | Continuously welded and corrugated aluminum |
| Construction - Circuit Identification | ICEA Method 3 K-2: Black insulation with printed numbers and colors |
| Construction - Conductor | Stranded, nickel coated copper |
| Construction - Fillers | As Required |
| Construction - Insulation | Proprietary Low Smoke Zero Halogen thermoset Fire-Roc layer and thermoset low smoke zero halogen covering |
| Construction - Outer Jacket | Flame Retardant Polyvinyl Chloride (PVC) or optional Low Smoke Zero Halogen (LSZH) polyolefin |
| Construction - Ground Wire(s) | Insulated ground |
| cUL Listing | CEC type ACIC IAW CSA 22.2 No. 239 |
| Performance Standards | 30 minutes at 2000°F (1093°C) Rapid Rise test , Modified IEC 60331-11 • 90°C Wet and Dry per NEC • IEC 60331-11 flame test modified to 3 hours @ 2000°F • Weather and sunlight resistant |
| Volts | 600 |
| UL Listings | NEC Type MC in accordance with UL Standard No. 1569 and MC-HL per UL Standard No. 2225 • -40°C • CT (Cable Tray) use • FT4 flame test designation • Type CWCMC to IEEE 1580 and UL 1309/CSA C22.2 No. 245 as marine shipboard cable |
| Product Category | Power, Circuit Integrity |
| Region | Canada |
| Applications | Fire & Life Safety |
| Market Served | Oil & Gas, Clean Energy |
| Temperature | 90ºC |
