Rock-Flex® DLO is a single conductor, power cable utilizing flexible Class K conductor suitable for use in applications requiring greater flexibility, robust mechanical properties and superior flex life. Applications include locomotive and car equipment, motor and generator leads, battery leads, shipyards, telecommunications power, heavy earth moving equipment, renewable energy and other heavy duty flexing applications. LSZH insulation is preferred for highly occupied environments or areas with large concentrations of equipment since it considerably reduces the amount of toxic and corrosive gas emitted during combustion. (IN22)
- Flexible Class K tinned copper conductor for improved terminations and corrosion resistance
- Low Smoke Zero Halogen design (LSZH)
- RoHS/REACH compliant and lead free.
- Irradiated thermoset insulation for enhanced thermal stability.
- Proprietary single-pass insulating/jacketing process allows for a significant overall diameter reduction (>12 - 15%) over standard two-pass designs saving valuable space in cabling pathways and providing an overall cost reduction
- Specially formulated insulation for superior two (2) years long term water resistance
- Superior flame and abrasion resistance
- Excellent mechanical properties including Abrasion, Notch Propagation, Cut Through and Heat Deformation
- Ease of strippability, no separator tape over conductor
- Low friction surface for reduced pulling tension
- Can be installed in Conduit, Duct, Raceway, Aerial or Direct Burial (when dual rated as Type USE-2)
- Can be used in -40°C to +125°C applications
