Surface and underground mining operations require cable solutions that can withstand the toughest conditions. Elements such as flexing, vibration, and impact found in harsh mining environments can make or break even the most rugged mining machinery. Marmon IEI understands how important high-performance and ruggedized cables are for critical power, control, and communications applications and offers a variety of specialized cables to meet any type of mining installation. From flexible power cables used in surface mining applications to MSHA-rated cables used in underground equipment, Marmon IEI has solutions that can perform in the toughest environment reducing downtime and keeping critical mining operations running.

Mining

Contact Sales Rep

Marmon IE&I Collection

Find Product Information, Download Submittals, Request Technical Services

Leaders in Innovative Design, Production, and Technical Support of Specialty Wire, Cable, Pre-Insulated and Steam Traced Tubing For Your Next Project

Property	Value
Applications	Harsh Environment Power Control Instrumentation
Construction - Bending Radius	6 x d (d = overall diameter)
Construction - Cable Type	Single Pair Shielded
Construction - Color Code	Black and white
Construction - Conductor	7-strand bare copper, Class B
Construction - Armor	Multiple strands of served galvanized steel wire (SWA)
Construction - Inner Jacket	Black FR-PVC
Construction - Outer Jacket	Black FR-PVC
Construction - Insulation	0.015 inch (0.4 mm) 105C FR-PVC
Construction - Number of Conductors Per Group	2
Construction - Shield	100% coverage, an aluminum-polyester tape shield and a 7-strand tinned copper drain wire
Market Served	Oil & Gas, Clean Energy
Performance Standards	Class I, Division 2 and Class II, Division 2 hazardous areas • NEC 2023 Article 722/335 • ICEA, IEC, BS standards or customized configurations • IEC 60332, IEEE 120
Product Category	Instrumentation
UL Listings	UL listed as PLTC/ITC • Manufactured in accordance with UL • UL 1685
Volts	300

Product Details

1853 - 300 Volt, PVC, Single Pair, Overall Shield, Served Wire Armor (SWA)

Applications

Description

Features

Data Sheet
