Product Details
| Property | Value |
|---|---|
| Construction - Binder Tape | Non-hygroscopic and non-wicking |
| Construction - Color Code | As specified by customer |
| Construction - Fillers | When required, flame retardant and non-hygroscopic |
| Construction - Insulation | Irradiation cross-linked Polyolefin, Exane® 125˚C |
| Construction - Outer Jacket | Black, Heavy Duty, Arctic Grade Neoprene. Sunlight resistant |
| Construction - Temperature Rating | Marmon IEI rated 125˚C, UL/CSA 110˚C, IEEE 100˚C |
| Construction - Overall Shield System | Aluminum/Polyester foil tape + tinned copper drain wire |
| CSA Listings | CSA C22.2 No. 245 X110 Marine Shipboard |
| Market Served | Oil & Gas, Clean Energy |
| Product Category | Control |
| Temperature | 125ºC |
| UL Listings | UL 1309 X110 Marine Shipboard Cable |
| Volts | 1000 |
| Construction - Armor (optional) | Bronze Braid – Standard. Tinned Copper Braid – Optional |
| Construction - Conductor | Flexible, soft annealed tinned copper per ASTM B33 & IEEE 1580 |
| Construction - Inner Jacket | Black, Heavy Duty, Arctic Grade Neoprene. Sunlight resistant |
| Applications | Harsh Environment Power Control Instrumentation |
| Performance Standards | IEEE 45/1580 Type P • Intertek Testing Service (ETL) certified as Type P • IEEE 1202 & FT-4 70,000 Btu/hr Vertical Tray Flame Tests • IEC 60332-3-22 Category A/F Flame Test • Type Approved by ABS, DNV GL and Lloyd’s Register NA • Armored & Sheathed cables are suitable for use in Class 1, Division 1 and Zone 1 hazardous locations • Unarmored cables are suitable for use in Class 1, Division 2 and Zone 2 hazardous locations |
