Product Details
| Property | Value |
|---|---|
| Construction - Armor | Interlock profile, corrosion resistant galvanized steel. Double armor may be supplied where extra protection is required |
| Construction - Barrier Tape | Bedding tape to protect the lead sheath. Rubber infused/ woven fabric |
| Construction - Conductor | Solid, tinned copper per ASTM B33 |
| Construction - Insulation | The insulation is a specially compounded, oil resistant EPDM rubber with proven electrical properties |
| Construction - Jacket | Oil resistant/low swell EPDM jacket that has been formulated for harsh conditions |
| Construction - Lead Sheath | A fatigue and corrosive resistant lead sheath. The lead sheath prevents decompression and is ideal for wells that are gassy and have high levels of H2S and CO2 |
| Industry Reference | Industry standard: • IEEE 1019 • API RP 11S5 • API RP 11S6 • ASTM A459 • ASTM B3 • ASTM D412 |
| Marker Tape | Footage, Manufacturer, Year • Or per customer’s request |
| Options | Stainless steel armor for increased protection in wells high in H2S and CO2 • Monel armor for maximum protection in wells extremely high in H2S and CO2 |
| Product Category | Pump |
| Standard Packaging | DIN heavy duty steel reel • Optional: Lagging • Optional: Multiple lengths per reel |
| Applications | Harsh Environment Power Control Instrumentation, High Temperature |
| Market Served | Oil & Gas |
| Temperature | 400ºC |
| Volts | 4000 |
