Product Details
| Property | Value |
|---|---|
| Construction - Binder Tape | Helically applied |
| Performance Standards | Third party qualification for 30 minutes at 2000°F (1093°C) Rapid Rise Test, modified IEC60331 with side bricks and 15A load • IEC 60331-11 flame test modified to 3 hours @ 2000°F • Sunlight Resistant” • “FT-4” flame test designation • ABS for marine shipboard • - crush and impact requirement of Type MC cable and used per NEC 336.10 (7) for extended runs |
| Volts | 600 |
| Construction - Conductor | Stranded, nickel coated copper |
| Construction - Insulation | Proprietary Low Smoke Zero Halogen thermoset Fire-Roc layer and themoset low smoke zero halogen covering |
| Construction - Circuit Identification | ICEA Method 3 Table E2: Black insulation with printed numbers and color names. In addition, legs other than black have colored stripe in the named color. Circuits of four conductor cables are identified black, red, blue, and green. |
| UL Listings | NEC Type TC with UL Standard No. 1277 • Singles wet rated per UL44/CSA 22.2 No. 38 Section 5.4 Long Term Insulation Resistance in Water Test and lType RHW-2/RW90 |
| cUL Listing | CEC Type CIC • CUL Listed as CEC Type TC • Type RHW-2/RW90 |
| CSA Listings | R90 in accordance with CSA C22.2 No. 38/UL44 • CSA Standard C22.2 No. 239 • CSA Standard C22.2 No. 230 |
| Construction - Jacket | Black Low-Smoke Zero Halogen Polyolefin (other colors available on request) Marmon |
| Construction - Ground Wire(s) | Insulated ground wire upon request |
| Region | Canada |
| Applications | Harsh Environment Power Control Instrumentation, Fire & Life Safety |
| Market Served | Oil & Gas, Clean Energy |
| Temperature | 90ºC |
| Product Category | Power, Circuit Integrity |
