Product Details
| Property | Value |
|---|---|
| Volts | 600 |
| UL Listings | ICEA standard S-66-524 and UL 44 for type XHHW-2 • UL VW-1 • Type TC-ER or TC-ER-HL for cable tray installations (UL 1277) |
| Construction - Conductor | Annealed, tin-coated copper, Class “B” strand (ASTM B-8 & B-33) |
| Performance Standards | ICEA standard S-19-81 for neoprene • Cable passes IEEE 1202/FT4 Flame Test • Single conductors pass the vertical flame tests specified in IEEE-383 1974 Para. 2.5.6 (ICEA S-19-81 Section 6.19.6) • NEC Class 1, Divisions 1 and 2 hazardous locations |
| Construction - Jacket | Black, heavy-duty neoprene |
| Construction - Insulation | Heat and moisture resistant, flame retardant crosslinked polyethylene |
| Construction - Ground Wire(s) | Annealed copper Class “B” strand, sized to comply with NEC requirements |
| Construction - Fillers | Flame retardant polypropylene, as required |
| Construction - Circuit Identification | Printed numbers per ICEA Method 4 |
| Construction - Binder Tape | Helically applied |
| Product Category | Power |
| Applications | Harsh Environment Power Control Instrumentation |
| Market Served | Mining & Industrial OEM |
| Temperature | 90ºC |
