FB72 - 300 Volt, Foundation Fieldbus, Multi Pair, Individual & Overall Shield, Served Wire Armor (SWA)
Applications
Harsh Environment Power Control Instrumentation
Description
Features
- Excellent electrical characteristics
- Flame Retardant
- Made in America
- Served Wire Armor offers cut-through resistance and is suitable for vertical drops
- 300 Volt rated insulation
| Property | Value |
|---|---|
| Applications | Harsh Environment Power Control Instrumentation |
| Construction - Armor | Multiple strands of served galvanized steel wire (SWA) |
| Construction - Bending Radius | 12 x d (d = overall diameter) |
| Construction - Cable Type | Multiple Pair - Individual & Overall Shield |
| Construction - Conductor | 7-strand bare copper, Class B |
| Construction - Inner Jacket | PVC, color-coded orange |
| Construction - Insulation | 0.025 inch XLPE for 18 AWG, 0.030 inch XLPE for 16 AWG |
| Construction - Outer Jacket | PVC, color-coded orange |
| Construction - Shield System | 100% coverage, an aluminum-polyester tape shield and a 7-strand tinned copper drain wire |
| Construction - Color Code | Blue and Brown |
| Market Served | Oil & Gas, Clean Energy |
| Performance Standards | ISA/50.02, FF-844 H1, IEC 61158-2 Type A fieldbus standards • Class I, Division 2 and Class II, Division 2 hazardous areas • NEC 725/727 |
| Product Category | Fieldbus |
| UL Listings | PLTC/ITC |
| Volts | 300 |
