Product Details
| Property | Value |
|---|---|
| Applications | Harsh Environment Power Control Instrumentation |
| Construction - Armor (optional) | Bronze Braid – Standard. Tinned Copper Braid – Optiona |
| Construction - Circuit Identification | Standard – Vivid pigmented insulation colors per IEEE 1580. Optional – Dk. Gray + No’s |
| Construction - Conductor | Flexible, soft annealed tinned copper per ASTM B33 & IEEE 1580 |
| Construction - Fillers | When required, flame retardant and non-hygroscopic |
| Construction - Inner Jacket | Black, Irradiation cross-linked Hypalon® (CSPE). Sunlight resistant |
| Construction - Insulation | Irradiation cross-linked Polyolefin, Exane® 125˚C |
| Construction - Outer Jacket | Black, Irradiation cross-linked Hypalon® (CSPE). Sunlight resistant |
| Construction - Temperature Rating | Black, Irradiation cross-linked Hypalon® (CSPE). Sunlight resistant |
| CSA Listings | CSA C22.2 No. 245 X110 Marine Shipboard |
| Market Served | Oil & Gas, Clean Energy |
| Product Category | Power |
| Temperature | 110ºC |
| UL Listings | UL 1309 X110 Marine Shipboard Cable |
| Volts | 1000 |
| Performance Standards | IEEE 45.8/1580 Type P • Intertek Testing Service (ETL) certified as Type P •IEEE 1202 & FT-4, 70,000 Btu/hr Vertical Tray Flame Tests •IEC 60332-3-22 Category A/F Flame Test •Type Approved •Armored & Sheathed cables - Class 1, Division 1 and Zone 1 hazardous locations •Unarmored cables - Class 1, Div 2 & Zone 2 •IEC 61892-4-Annex D • NEK 606 |
